輸入 input Voltage ·23-26VDC Input Frequency · Input Current ·7.2A max at 24Vdc, full load Inrush Current · Input Protection ·24VDC：Internal fuse Protection
|
輸出(chu) Output Voltage ·V: 54VDC Output Voltage Trim ·V: 57VDCmax Initial Set Accuracy ·NOR Rated Load ·120±3mA * 24Channel Open Lamp Protection · Shutdown & ERR Signal:an active-high TTL-compatible
|
|
常規 Efficiency ·Up to 95% at rating load Isolation ·NOR Control Signals ·VBLON MTBF ·100000H or more Environmental Operating Temperature ·0°C to +50 °C Cooling ·Forced air cooling Operating Humidity ·20%~85% RH, non-condensing Storage Temperature ·-20 °C ~ +70 °C Non binding Operating Altitude ·3000 m max Shock ·Operating 5g, No Operating 30g, X, Y, Z in each direction, each of the 3 back Vibration ·3mm, 5HZ to 20KHz, 3axes
|
EMC & 安(an)全(quan) Emi ·EN55013 Class B、GB13837 Class B 、FCC Class B EN55024 Class B、IEC6100-3、EN6100-3 Ems ·GB17626-1998、IEC61000 Safety Approvals ·UL60065、 EN60065 、GB8898-2001
|
