輸入電壓               · 85-110 VAC

輸入頻率               · 47-63 Hz

輸入電流               · 2.9 A typical at 85 VAC, full load

浪涌電流               · 30 A max at 110 VAC, cold start at 25 °C

輸入保護               · Internal T5.0 A/250 V fuse in line

and neutral

輸出

輸出電壓              · V1: -24V V2: 5 VDC

輸出電流              · V1: 4A V2: 8A

輸出電壓修正         · ±3% (see Mechanical Details)

初始設置精度         · ±0.5% V1, ±0.5% V2

啟動延遲              · 1S  typical

啟動上升時間          · 0.2S max

保持時間          · 20mS min at 100 VAC

常規：

功效                   . Up to 80%

隔離                  · 1200 VAC Input to Output

  . 1200 VAC Input to Ground

MTBF                 · 60000 Hrs or more  at35 °C.

環境

工作溫度             · 0 °Cto +50 °C

冷卻                 · Convection cooled

工作濕度             ·15% to 85% RH

儲存溫度             ·-10 °Cto +75 °C

工作高度             ·3000 m

振動                 ·3 mm, 5 Hz to 20 kHz, 3 axes
